THE VICTORIAN – 9 COLUMN
Instantly recognisable, we’ve created the Victorian 9 column radiator by taking a mould of an original Ideal Standard Radiator from the National Radiator Company.
Unlike the Neo–Classic style, the Victorian has a flat foot on each leg section that helps to prevent damage to floor coverings in the home by spreading its weight more evenly.
All our radiators are finished using a black primer. Alternately, if you wish, why not let us paint them from one of the thousands of Ral colours or our specialised finishes. Below are samples of the many colours that can be used to give you a classic, modern or contemporary look.
Simply ring your nearest dealer or download our brochure for full customisation options.
DIMENSIONS
LEG SECTION HEIGHT
330mm
MIDDLE SECTION HEIGHT
282mm
SECTION LENGTH
56mm
SECTION DEPTH
334mm
INLET & EXIT
280mm
BOTTOM INLET TO FLOOR
76mm
TOP INLET TO FLOOR
295mm
INLET TO SKIRTING
167mm
HEAT OUTPUT PER SECTION
DELTA ∆T 50˚C
101 Watts / 344BTUs
DELTA ∆T 60˚C
130 Watts / 443BTUs
WEIGHT
EMPTY WEIGHT PER LEG SECTION
7.2 Kgs
EMPTY WEIGHT PER MIDDLE SECTION
6.8 Kgs
*All measurements and sizes are approximate.
CLASSIC SUITE
*All RAL swatches below are examples and may not be true to colour shown here, please check with your dealer for a specific RAL colour.
RAL 1001
RAL 3002
RAL 3014
RAL 4002
RAL 5013
RAL 6004
RAL 7005
RAL 8008
MODERN SUITE
RAL 1028
RAL 2002
RAL 3005
RAL 8016
RAL 4006
RAL 5005
RAL 6025
RAL 7016
CONTEMPORARY SUITE
RAL 1006
RAL 1019
RAL 2009
RAL 3011
RAL 4008
RAL 5002
RAL 6032
RAL 7008
